Carriage and Reach Assembly
During a typical work shift, both the reach assembly and the carriage receive a large amount of stress. High durability of these items is certainly required to be able to ensure that the truck keeps productivity levels high. Yale reach devices are engineered using heavy-duty components for long life and durability. The reach assembly is cushioned at the end of the stroke for better operator ergonomics and great durability. In addition, excellent visibility is provided with the open carriage design and the optimal hose routing.
The Reach Assembly Rear Carrier provides rigidity and durability by being mounted on angled load rollers so as to resist side to side forces. Furthermore, the stronger inner frame assembly helps to endure shocks and vibration while handling load. The thick inner frame's side weldments have also been designed for durability.
The Reach Arm Mechanism is made up of tapered roller bearings at reach mechanism pivot points. The pivot points help to decrease the movement side to side and the twisting of the reach assembly during rough tasks. In order to lessen carriage twisting, dual reach cylinders are mounted. There are key pivot points which have grease fittings in order to guarantee longer service life by providing lubrication.
Routed through a flexible track in order to decrease potential damage and binding are various hoses and wires. The carriage is another essential component. There is Reduced Carriage Travel Speed offered with Carriage Extended option in order to prevent high speed travel with the reach assembly extended. This helps to decrease stress on the reach mechanism itself.
Mast
A crucial part to both the truck's overall uptime and the operator's confidence come from the mast's rigidity and durability. This is especially true at the tall lift heights where the reach trucks operate. The mast should be rigid enough to endure any twisting caused by any off-center loading issues or the truck's motion. The mast should be sure it could lower and rise in a smooth way with the least consumption of power.
